Configurazione di prova
Configurazione per i test a basso livello: sistema di archiviazione standard di riferimento
Abbiamo usato il sistema standard di test, che usiamo in queste comparative per tutti i benchmark a basso livello di prestazioni. Questo sistema è lo stesso da circa 3 anni, quindi possiamo comparare centinaia di dischi.
Hardware | Processore | 2x Intel Xeon 3.6 GHz, FSB800, 1 MB L2 Cache | Piattaforma | Asus NCL-DS, Intel E7520 Chipset, BIOS 1005 | RAM | Corsair CM72DD512AR-400 (DDR2 -400 ECC, reg.) |
| 2x 512 MB, CL3-3-3-10 Timings | Hard Drive di sistema | Western Digital Caviar WD1200JB |
| 120 GB, 7,200 RPM, 8MB Cache, UltraATA/100 | Controllers d'archiviazione | Intel 82801EB UltraATA/100 Controller (ICH5) |
| Promise SATA 300TX4 |
| Promise FastTrak TX4310 |
| Driver 2.06.1.310 | Rete | Broadcom BCM5721 On-Board Gigabit Ethernet NIC | Grafica | Integrated ATI RageXL, 8MB | Software | Misura Prestazioni | c't h2benchw 3.6 |
| PCMark05 V1.01 | Prestazioni I/O | IOMeter 2003.05.10 |
| Fileserver-Benchmark |
| Webserver-Benchmark |
| Database-Benchmark |
| Workstation-Benchmark | Software & Drivers di sistema | SO | Microsoft Windows Server 2003 Enterprise Edition, |
| Service Pack 1 | Driver Piattaforma | Intel Chipset Installation Utility 7.0.0.1025 | Driver Frafici | Default Windows Graphics Driver |
|
Piattaforma notebook per test sull'efficienza: Dell Latitude D630
Abbiamo aggiunto un test sulla prestazione per watt usando un notebook Dell Latitude D630, e realizzato tre prove. La prima, IOMeter, incentrata sulle operazioni di I/O dell'ambito workstation. La seconda, anch'essa basata su IOMeter, focalizzata sulle prestazioni di lettura in streaming, che permettono ai dischi di operare vicino al massimo throughput sequenziale.
Abbiamo rilevato i risultati riguardanti prestazioni, consumo medio e rapporto prestazione per watt. La terza prova ha riguardato il consumo medio del disco richiesto per fornire un piccolo flusso di dati sequenziale. Per fare ciò, abbiamo avviato un file.vob (DVD) sugli hard disk di prova.
Piattaforma | Notebook | Dell Latitude D630 |
| Mobile Intel GM965 Express Chipset | CPU | Intel Core 2 Duo T9500 |
| 45 nm; 2.6 GHz; 6 MB L2 Cache | RAM | Corsair ValueRAM 2x 2048MB DDR2-667 | Drive | Hitachi HTS722016K9A300 |
| 160 GB; 7,200 RPM; 16 MB Cache; SATA 3 Gb/s | DVD-ROM | 8x DVD+/-R | Rete WiFi | Intel 4965 WLAN (802.11a/g/n) | Schermo | 14.1" WXGA+ (1400x900) | Scheda Grafica | Intel GMA X3100 | Alimentatore | 9-Cell/85WHr Battery | Software e Driver di sistema | SO | Windows Vista Ultimate 6.0 Build 6000 SP1 | DirectX | 10 | Driver Piattaforma | Version 8.2.0.1014 | Driver Grafici | igdum32.dll (7.14.00.10.1253 |
|
